HubWayLD Active Isolated Unit - 5 -
1 - White/Orange [VIDEO +]
2 - Orange [VIDEO -- ]
3 - White/Green [DATA +]
4 - Blue [AC 1]
5 - White/Blue [AC 2]
6 - Green [DATA -- ]
7 - White/Brown [AC 2]
8 - Brown [AC 1]
Fig. 3 - CAT-5 Structured Cable Wiring Color Codes and PIN Configurations
VIDEO BALUN/COMBINER
CAT5 + DATA-- POWER
AC
VIDEO
HubWayAv
VIDEO
AC Power
to Camera
Data to
Camera --
+ Data to
Camera
Green Power LED
12VDC Power
to Camera +
--
Red Power LED
Wire
Connectors RJ45 Jack RJ45 Jack
To BNC
Connector
of Camera
To BNC
Connector
of Camera
Structured
Cable from
HubWayLD8Di
or
HubWayLD16Di
Structured
Cable from
HubWayLD8Di
or
HubWayLD16Di
VIDEO BALUN/COMBINER
HubWayDv
CAT5 + DATA-- -- 12VDC+
--
+
Wire
Connectors
* Also Available as:
HubWayDvi
Video Balun/
Combiner
for non-isolated
12VDC cameras
Fig. 2
Fig. 2c Fig. 2a
Fig. 2b Fig. 2d
HubWayAv passes AC voltage from pins 4, 5, 7, 8 to
terminals marked [AC Power] (Fig. 3, pg. 5). HubWayDv/HubWayDvi converts AC voltage to DC
voltage from pins 4, 5, 7, 8 to terminals marked
[-- 12VDC +] (Fig. 3, pg. 5).
HubWayAv, HubWayDv and HubWayDvi Video Balun/Combiners:
HubWayAv *24VAC/28VAC *24VAC/28VAC 24VAC cameras Green
HubWayDv *24VAC/28VAC 12VDC 12VDC cameras Red
HubWayDvi *24VAC/28VAC 12VDC electronically isolated 12VDC cameras w/o isolation Red
Altronix
Model
Number
Output
V
oltage
to camera
Input
V
oltage
from HubW
ay
unit Camera
Type
Po
w
er LED
*Based on camera load and structured cable length.
