ReServ4WP Outdoor Video Surveillance UPS is designed to simultaneously
provide power for 24VAC and 12VDC cameras during normal or power
outage conditions. True sine wave regulated AC outputs and regulated DC outputs.
Overview
Specifications
®
®
ReServ4WP
Agency Approvals
European Conformity
Input:
• 115VAC 60 Hz, 3.5 amp.
Output:
• 4 individually PTC protected outputs
configured as follows:
• Two (2) outputs @ 24VAC. PTCs rated @ 4 amp.
• Two (2) outputs @ 12VDC. PTCs rated @ 1 amp.
• Total supply current:
- 24VAC @ 4 amp max.
- 12VDC @ 1 amp.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switchover to stand-by battery
when AC fails.
Stand-by Batteries
4 amp (100VA) load
at 24VAC and 1 amp load
at 12VDC max.
Two (2) 12VDC/7AH
45 minutes
Two (2) 12VDC/12AH
90 minutes
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
Electrical:
• Operating temperature: -33º C to 42º C ambient.
• 45 BTU/Hr.
• System AC input VA requirement: 402.5VA.
Features:
• AC/DC power LED indicators.
• Four (4) power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• True sine wave regulated AC outputs and
regulated DC outputs.
• Audible alarm provides notification of
UPS trouble conditions.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
Mechanical:
• NEMA4 / IP66 Rated Enclosure.
• Integral flanges simplify wall or pole mounting.
• Enclosure Dimensions (H x W x D approx.):
17.5” (444.5mm) x 12” (304.8mm) x 6.625” (168.3mm)
• Enclosure accommodates up to
two (2) 12VDC/12AH batteries.
• Product weight (approx.): 21.5 lbs. (9.75 kg).
• Shipping weight (approx.): 23.0 lbs. (10.43 kg).
PMK1 Pole Mount Kit (order separately)
PMK1 pole mount kit is designed to simplify installation of outdoor units.
• Accommodates 2”- 8”(diameter) poles.
• Kit includes:
- Two (2) powder coated steel mount brackets.
- Four (4) stainless steel bolts.
- Four (4) stainless steel lock washers.
- Two (2) wormgear quick release straps.
PMK1
