Altronix AL400ULMR Data Sheet User Manual

Al400ulmr multi-output power supply/charger

background image

Input:

• Input 115VAC / 60Hz, 3.5 amp.
• Input fuse rated @ 5 amp/250V.
• Fire Alarm Panel or Access Control System trigger
inputs. N.O. or N.C. supervised trigger input and
polarity reversal trigger input.

Output:

• 12VDC or 24VDC selectable outputs.
• 12VDC @ 4 amp or 24VDC @ 3 amp supply current.
• Burglar Alarm Applications:
12VDC = 10VDC-13.2VDC;
24VDC = 20VDC-26.4VDC.
• Five (5) PTC protected Class 2 Rated power limited
outputs, rated @ 2 amp.
• Output relay energizes when unit is triggered
(form “C” contact rated 1 amp @ 28VDC).
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.

Battery Backup:

• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switch over to stand-by battery
when AC fails.
• Maximum charge current 0.7 amp.

Supervision:

• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
• Battery presence supervision (form “C” contacts).
• Power fail supervision relay (form “C” contacts).

Visual Indicators:

• AC input and DC output LED indicators
(power supply board).
• Red LEDs indicate condition of power outputs
(multi-output board).
• Power & input trigger LEDs (multi-output board).

Electrical:

• Operating temperature: 0º C to 49º C ambient.
• BTU/Hr.:
- 12VDC: 24.57 BTU/Hr.
- 24VDC: 36.85 BTU/Hr.
• System AC input VA requirement: 402.5VA.

Mechanical:

• Enclosure Dimensions (H x W x D approx.):
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm)
- Accommodates up to two (2) 12VDC/7AH batteries.
• Product weight (approx.): 7.6 lbs. (3.45 kg).
• Shipping weight (approx.): 8.6 lbs. (3.9 kg).

Specifications

Agency Approvals

Altronix Corp.

140 58th St. Brooklyn, NY

UL Listed for Access Control Systems Units
(UL 294).
UL Listed Standard for Power Supplies for Use
with Burglar-Alarm System Units (UL 603).
UL Listed Hospital Signaling and Nurse Call
Equipment (UL 1069).
UL Listed Standard for Safety for Fire
Protective Signaling Systems (UL 1481).

AL400ULMR

Multi-Output Power Supply/Charger

Rev. DSAL400ULMR - 07112013

AL400ULMR multi-output access control power supply/charger is specifically
designed for use with access control systems and accessories. This unit con-
verts a 115VAC / 60Hz input into five (5) individually protected Class 2 Rated
power limited 12VDC or 24VDC outputs. Each output will route power to a va-
riety of access control hardware devices including Mag Locks, Electric Strikes,
Magnetic Door Holders, etc. These outputs will operate in both Fail-Safe and
Fail-Secure modes. Controlled trigger input is achieved through normally open
(N.O.) or normally closed (N.C.) supervised input or the polarity reversal from
an FACP (Fire Alarm Control Panel). A form “C” dry output relay enables
HVAC Shutdown, Elevator Recall or it may be used to trigger auxiliary devices.

CSFM - California State Fire

Marshal Approved.

MEA - NYC Department of

Buildings Approved.

Overview

AL400ULMR
