Rac120 relay modules

background image

UL Recognized.

CSA Approved.

Agency Approvals

Input Voltage:

• 120VAC operation.
• Current draw: 12mA.

Contact Rating:

• 10 amp/220VAC or 28VDC DPDT contacts.

Electrical:

• Operating temperature: -- 25º C to 55º C ambient.
• System AC input VA requirement: 14.4VA.

Mechanical:

• DIN Rail mountable.
• Dimensions (L x W x H approx.):
2.7” (68.58mm) x 1.375” (34.93mm)
x 2.375” (60.32mm)
• Product weight (approx.): 0.38 lbs. (0.172 kg.).
• Shipping weight (approx.): 0.4 lbs. (0.181 kg.).

RAC120 is a DIN rail mountable relay which is designed for continuous duty. This rugged,
reliable and dependable relay will handle any switching application.

RAC120

Relay Modules

Rev. DSRAC120_01192012

Overview

Specifications

Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com

RAC120
