Video Balun/Combiners
Video from Camera
Data to Camera
Power to Camera
Cat5
back to
HubWay
or
HubSat
HubWayAv2 - Slim-line Video Balun/Combiner
compatible with all HubWay UTP Hubs
for AC or DC fixed cameras or PTZs.
Refer to the HubWay Video Balun/Combiner
Installation Guide Rev. 123008
12VDC
-- +
RJ45
DATA
+ --
VIDEO
Commercial
CCTV Accessory
3C03
HubWayDv
VIDEO BALUN/COMBINER
Wire
Connectors
Red
Power LED
+ 12VDC Power
--- to Camera
--- Data
+ to Camera
To BNC
Connector
of Camera
Structured
Cable from
HubWayH16
RJ45 Jack
HubWayDv - Video Balun/Combiner
compatible with all HubWay UTP Hubs for DC
fixed cameras or PTZs.
HubWayDvi - Video Balun/Combiner
built-in isolation. Compatible with all HubWay
UTP Hubs for DC fixed cameras or PTZs. With
or without internal isolation.
Enclosure Dimensions
(H x W x D) (approximate)
:
1.625” (41.275mm) x 19.125” (486mm) x 8.5” (216mm)
1.625"
41.28mm
8.5"
215.9mm
.75"
19.05mm
19.125"
485.78mm
17.625"
447.67mm
16
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE
AC POWER
GAIN
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
CH 1-4
CH 5-8
28VAC
OFF
24VAC
+ DATA --
1-8
+ DATA --
9-16
5
6
7
8
9
10
11
12
CH 9-12
28VAC
OFF
24VAC
13
14
15
16
CH 13-16
