Overview:
The AL400ULX is a power supply that converts a 115VAC / 60Hz input, to a 12VDC or 24VDC regulating output,
(see specifications below). The AL400ULX is the base power supply unit for the UL Listed multi-output power
supply/charger series: AL400ULPD4, AL400ULPD4CB, AL400ULPD8, AL400ULPD8CB, AL400ULXPD16,
AL400ULXPD16CB (Refer to AL400ULX Series Power Supply Configuration Reference Chart below).
AL400ULX Series Power Supply Configuration Reference Chart:
Altronix
Model Number
Accessory Power Distribution Module(s) Number of Outputs Fused Outputs PTC Outputs 12VDC Total Output Current (amp) 24VDC Total Output Current (amp) Individual Ouput Rating (amp) Power Supply Input Fuse Rating Power Supply Ouitput Fuse Rating Ag
ency Listings
UL Listings and File Numbers
AL400ULX
AL400ULXX
AL400ULXR
---- 1 --- --- 4 3 ---
5A/
250V
15A/
32V
UL File # S4707
UL 294
UL Listed for Access
Control System Units.
UL 603
UL Listed for Power
Supplies for Use with
Burglar-Alarm Systems.
UL 1069
UL Listed Hospital
Signaling and Nurse
Call Equipment.
UL 1481
UL Listed for
Power Supplies for
Fire Protective
Signaling Systems.
AL400ULPD4 PD4UL
4
x ---
4 3
3.5
5A/
250V
15A/
32V
AL400ULPD4CB PD4ULCB --- x 2.5
AL400ULPD8 PD8UL
8
x --- 3.5
5A/
250V
15A/
32V
AL400ULPD8CB PD8ULCB --- x 2.5
AL400ULXPD16
Two (2)
PD8UL
16
x --- 3.5
5A/
250V
15A/
32V
AL400ULXPD16CB
Two (2)
PD8ULCB
--- x 2.5
Do not exceed total output rating of 4 amp @ 12VDC or 3 amp @ 24VDC per unit.
Specifications:
Power Supply Output Specifications:
Output Switch Position
12VDC SW1 - CLOSED (Fig. 1b)
24VDC SW1 - OPEN (Fig. 1b)
Input:
• Input 115VAC / 60Hz, 3.5 amp.
• AC input and DC output LED indicators.
Output:
• Class 2 Rated power-limited output(s).
• 12VDC or 24VDC selectable output.
Burglar Alarm Applications (UL 603):
12VDC = 10VDC-13.2VDC.
24VDC = 20VDC-26.4VDC.
• 4 amp total supply current at 12VDC
or 3 amp total supply current at 24VDC.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
• Output fuse rated at 15A/32V.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when
AC fails.
• Maximum charge current 0.7 amp.
• Zero voltage drop when switched over to battery backup.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery and battery presence supervision
(form “C” contacts).
Additional Features:
• Power supply, enclosure, cam lock and battery leads.
• All models are available in red enclosure
(add an “R” suffix to the part # e.g. AL400ULPD8R).
