Maximal11E provides system designers and installers with “maximum” power choices
and the highest levels of versatility. It provides 12VDC, 24VDC, or 12VDC and 24VDC
simultaneously via two (2) single output power supply/chargers. It includes AC fail, low
battery and battery presence monitoring. Optional Altronix

®

field installable UL Listed

sub-assemblies provide multiple outputs and a wide range of features for specific Access
Control and Fire Alarm applications.

Maximal11E

Expandable Power System

Rev. DSMaximal11E - 06172013

Overview

Specifications

Optional Field Installable UL Listed Sub Assembly Modules

Maximal11E

Location A - ACM4, ACM4CB, MOM5, PD4UL, PD4ULCB,
PD8UL, PD8ULCB, PD16W & PD16WCB.

A

Power Supply

Power Supply

Stand-by

Battery

(optional)

Stand-by

Battery

(optional)

Stand-by

Battery

(optional)

Stand-by

Battery

(optional)

B

C

Location B - ACM4, ACM4CB, ACM8, ACM8CB, MOM5,
PD4UL, PD4ULCB, PD8UL, PD8ULCB, PD16W & PD16WCB.

Input:

• 115VAC 60Hz, 4.5 amp input.

Output:

• 12VDC and/or 24VDC outputs.

• Maximum output current:

Options

P/S 1

P/S 2

A 12VDC @ 3.5 amp

12VDC @ 3.5 amp

B 24VDC @ 2.7 amp

24VDC @ 2.7 amp

C 12VDC @ 3.5 amp

24VDC @ 2.7 amp

• Class 2 Rated power limited outputs.

• Filtered and electronically regulated outputs (built-in

power supply).
• Thermal and short circuit protection with auto reset.

Fuse Ratings:

• Power Supply input fuse rated @ 3.5 amp/250V.

Features:

• AC fail supervision (form “C” contact).

• Low battery and battery presence supervision
(form “C” contact).

Battery Backup:

• Built-in charger for sealed lead acid or gel type

batteries.

Battery Backup (cont’d):

• Maximum charge current 0.7 amp per p/s board.

• Automatic switch over to stand-by battery when

AC fails.

• Zero voltage drop when unit switches over to battery
backup (AC failure condition).

Visual Indicators:

• AC input and DC output LED indicators.

Electrical:

• Operating temperature: 0º C to 49º C ambient.

• BTU/Hr.:

- 12VDC: 43.00 BTU/Hr.

- 24VDC: 66.33 BTU/Hr.

- 12VDC & 24VDC: 54.66 BTU/Hr.
• System AC input VA requirement: 517.5VA.

Mechanical:

• Enclosure Dimensions (H x W x D approx.):
26” x 19” x 6.25” (660.4mm x 482.6mm x 158.75mm)

• Enclosure accommodates up to four (4)

12AH batteries.

• Product weight (approx.): 42.3 lbs. (19.17 kg).

• Shipping weight (approx.): 46.3 lbs. (21.00 kg).

Location C - ACM4, ACM4CB, ACM8, ACM8CB, MOM5,
PD4UL, PD4ULCB, PD8UL, PD8ULCB, PD16W & PD16WCB.
