T1656C AC transformer provides 16VAC with a total of 3.5 amp output current.
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
T1656C AC Transformer
Rev. DST1656C - 12102012
Overview
Specifications
Enclosure Dimensions (H x W x D approx.)
5.625” x 7” x 4.5” (142.88mm x 177.8mm x 114.3mm)
T1656C
Input:
• 120VAC 50/60 Hz, 0.5 amp.
Output:
• 16VAC/56VA (3.5 amp).
Electrical:
• Operating temperature: --- 20º C to 49º C ambient.
• BTU/Hr.: 28.66 BTU/Hr.
• System AC input VA requirement: 60VA.
Features:
• Fused input protection.
• Green grounding lead.
Mechanical:
• Product weight (approx.): 6 lbs. (2.72 kg).
• Shipping weight (approx.): 7 lbs. (3.18 kg).
1.75”
(44.45mm)
1.75”
(44.45mm)
3.00”
(76.2mm)
5.50”
(139.7mm)
1.65”
(41.91mm)
1.65”
(41.91mm)
0.625”
(15.88mm)
1.30”
(33.02mm)
1.30”
(33.02mm)
4.45”
(113.03mm)
1.80”
(45.72mm)
1.80”
(45.72mm)
4.45”
(113.03mm)
7.00”
(177.8mm)
