StrikeIt2
LED Diagnostics:
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level.
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage both at
battery terminal and at the board terminals marked [-- BAT +] to insure there is no break in the battery connection wires.
Note: Maximum charging current under discharge is 300mA.
Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed.
Caution: For continuous protection against risk of electric shock and fire hazard, replace input fuse with the same type
and rating 6.3 amp/250V. Do not expose to rain or moisture, indoor use only.
Terminal Identification:
Terminal Legend
Function/Description
-- AUX +
23.2-24VDC Auxiliary Output @ 0.5 amp.
-- BAT +
23.2-24VDC Stand-by Battery Connection (Two (2) 12VDC batteries wired in series).
-- OUT +
Connect 24VDC Panic Hardware Device, up to 16 amp 300 ms., .5 amp on hold.
GND / NO
Normally Open [NO] trigger input controls output. A maintained contact closure
will extend the unlock period.
LED
LED Status
Panic Device Power Controller Status
AC Power
Green
On
Normal operating condition.
Off
Loss of AC.
Red
On
24VDC output operating normal condition.
Off
24VDC output is not operational.
