Tighten fixing screws (5)
l
Check if the source holder is in position OFF
l
Attach the complete drive unit from above - when attaching make
sure that the two straps of the adapter disc and the drive unit are
on top of the other (B)
l
Fasten drive unit with the three fixing screws - drive unit (2)
l
Fit the padlock (3) and lock, to protect the source capsule against
unauthorized access
l
Attach new seal (4)
l
Connect pneumatic and feed lines - see operating instructions of
the source container
l
Remove padlock - Switching function (1)
l
Insertion or exchange of the source is hence finished
