VEGAMET 601, 602 7
Ambient conditions
Permissible ambient temperature -20°C … +60°C
Storage and transport temperature -40°C … +70°C
Current output
Number 1 output
Function analogue output of the evaluated data
Range 0/4 … 20 mA
Load max. 500 Ohm
Resolution 0.05 % of range
Linearity error 0.05 % of range
Temperature error 0.08 %/10 K of range
Voltage output
Number 1 output
Function analogue output of the evaluated data
Range 0 … 10 V
Current max. 1 mA
Resolution 0.05 % of range
Linearity error 0.05 % of range
Temperature error 0.08 %/10 K of range
Relay output (only with VEGAMET 602)
Number 1 output
Contact 1 floating spdt each
AgNi and hard gold plated
Turn-on voltage min. 10 mV DC
max. 250 V AC, 60 V DC
Switching current min. 10 µA DC
max. 3 A AC, 1 A DC
Breaking capacitance max. 500 VA, 54 W
Indicating elements
LED in front plate green on: operating voltage on
red: fault signal (only on VEGAMET 602)
Analogue indication 11 segments, 0 % … 100 %
Functions
Integration time 0 … 20 sec.
Adjustable current output 0 … 20 mA/4 … 20 mA
Adjustment elements
On front plate two potentiometers for adjustment of the
empty and full adjustment
On top, laterally DIL switch
- adjustment of the current output
0 … 20 mA/4 … 20 mA
- integration time
Product description
