6 VEGAMET 601, 602
Product description
1.4 Technical data
General data
Power supply
Operating voltage 20 … 250 V AC, 50/60 Hz
20 … 72 V DC
emergency power supply with curve shape ex-
tremely deviating from sine: U
max.
= 125 V AC
(rectangle)
Power consumption max. 3 W (3 … 18 VA)
Fuse T 1 A, 250 V
Meas. data input
Number 1 current input
Type of input active two-wire input analogue (sensor powered
by signal conditioning instrument)
Range 4 … 20 mA
Sensor capacitive electrodes
hydrostatic pressure transmitters
process pressure transmitters
Sensor power supply
- VEGAMET 601
24 V DC
- VEGAMET 602 Ex approx. 15 … 18 V DC
Current limitation at 24 mA, permanently shortcircuit proof
Connection cable 2-wire (standard cable)
Resistance per conductor
- VEGAMET 601
max. 250 Ohm
- VEGAMET 602 Ex max. 35 Ohm
Electrical connection
Screw terminals max. 1.5 mm 2
Electrical protective measures
Protection
- instrument
IP 30
- plug-in socket IP 20
Protection class II
Overvoltage category II
Mechanical data
Series module unit with plug-in socket, incl. transparent
cover, cover for the special terminals, coded
pin, two bonding jumpers
Mounting carrier rail mounting acc. to DIN 46 277, Bl. 3
Dimensions unassembled W = 36 mm, H = 118.5 mm, D = 134 mm
Weight approx. 170 g
