VEGAPULS 43 – 4 … 20 mA 9
26626-EN-041227
Types and versions
Survey of features
General features
• Application preferably for liquids in storage tanks and process vessels with increased
accuracy requirements.
• Measuring range 0 … 10 m or 0 … 20 m.
• Ex approved in Zone 1 (IEC) or Zone 1 (ATEX) classification mark
EEx ia [ia] IIC T6.
• Integrated measured value display.
Survey
Signal outputs
- active (4 … 20 mA)
- passive (4 … 20 mA, loop powered)
Process fitting, optionally available with
- DN 50; ANSI 2“
- DN 80; ANSI 3“
- DN 100; ANSI 4“
- DN 150; ANSI 6“
- TRI-Clamp (50, 80)
- hygienic fitting (50, 80)
Adjustment
- P C
- adjustment module in the sensor
- adjustment module with external indicating instrument
- HART
® handheld
Measuring range
- DN 50, ANSI 2“
0 … 10 m
- DN 80, ANSI 3“ 0 … 20 m
- DN 100, ANSI 4“ 0 … 20 m
- DN 150, ANSI 6“ 0 … 20 m
- TRI-Clamp 50, 80 0 … 10 m
- hygienic fitting 50, 80 0 … 10 m
2 Types and versions
2.1 Type survey
VEGAPULS 43 sensors are manufactured
with three process connections:
- flange connections (block flanges) in
DN 50, 80, 100, 150, ANSI 2“, 3“, 4“, 6“
- TRI-Clamp 2“
- hygienic fitting DN 50.
