6
Supply voltage Usable adapter
Battery Voltage Min. Max. type
1.2V 6.5V 10V PS905
2.4V 7.5V 11V PS905
3.6V 9.6V 12V PS905
4.8V 10.5V 13V PS1205
6V 12V 15V PS1205
7.2V 13.2V 16V PS1505
8.4V 14.5V 17V PS1505
9.6V 15.6V 18V PS1505
10.8V 16.8V 19V /
12V 18V 21V /
Determining the supply voltage :
This table indicates the minimum and maximum voltages to supply the charger.
Example:
To charge a 6V battery a minimum supply voltage of 12V is needed, the maximum voltage is then 15V.
Charging batteries
