SPICER DRIVE AXLE SERVICE KITS
28
Seals - Forward Output Location
Spicer Model
Spicer Part
Number
Notes
D344, 404, 405, 454, DSH40, 44, DST40, 41 127592 Microlip XL design
44DS, DS340, 380, 400, DS341, 381, 401, 402, 403, DT341, 381, 402 119431 Triple Lip Viton design - used until 1990,
replaced by triple lip design #127720 in tan-
dem models only!
127720 Microlip XL design - replaced the 119431
triple lip seal in these models and this loca-
tion in 1990
N340S, N400i, S400S 401HH103 Used after July 1991. Triple Lip design
(brown) *note1
J400S, W460S, S400S GGAHH104 Original design part before July 1991
472HH101 Used After July 1991. Triple Lip design
(brown) *note1
D461, 462, 463, 521, 581, 601, 651, 652 210737 Microlip XL design - replaced the 119429
triple lip seal in these models and this loca-
tion
Note 1: After March 1993, as a running change, the seal design was changed to Triple Lip design with vents (brown seal lips)
Note 2: Some seals are designed for specific models and may not be backwards compatible to older generation models or models in
unique applications like front drive steers. It’s best to know seal dimensions if not sure.
Seals - Steer Axles - Knuckle Seal Location
Spicer Model
Spicer Part
Number
Notes
I-120 120HH100 Nominal I.D. 1.92"
I-120SA, I-140 140HH100 Nominal I.D. 1.86"
I-160 160HH100 Nominal I.D. 2.05"
EFA-12F4, EFA-13F5 1004783 Nominal I.D. 1.66"
I-132 580325C1 Nominal I.D. 1.65"
I-90 418397C91 Nominal I.D. 1.61"
Seals - Wheel Ends - Hub Seal Location
Spicer Model
Spicer Part
Number
Notes
Misc Steer Axles 810196 Seal I.D.: 5.906
Misc Steer Axles 822072 Seal I.D.: 5.906
