SPICER DRIVE AXLE SERVICE KITS
23
597236C91 3.54 390KY101-X 16” Hypoid Gearing
597237C91 3.73 390KY101-X
597238C91 3.91 390KY101-X
J-Series 597239C91 4.10 390KY101-X
175, 190, 210, 220, 340,
380, 400
597240C91 4.44 390KY101-X
597241C91 4.78 390KY101-X
047KG100 X 5.11 390KY101-X
597242C91 5.38 390KY101-X
047KG101 X 5.63 390KY101-X
597243C91 6.14 390KY101-X
597244C91 6.57 390KY101-X
597245C91 7.17 390KY101-X
597246C91 8.17 390KY101-X
MJAKG137 X 3.70 / 5.05 N/A
MJAKG146 X 3.90 / 5.32 N/A
MJAKG132 X 4.11 / 5.60 N/A
M190T, M210T, M220T,
M230T
MJAKG133 X 4.56 / 6.22 N/A
MJAKG112 X 4.56 / 6.22 N/A Special kit complete w/bearings & seals
MJAKG119 X 4.89 / 6.66 N/A
MJAKG109 X 4.89 / 6.66 N/A Special kit complete w/bearings & seals
MJAKG134 X 5.29 / 7.21 N/A
MJAKG120 X 5.57 / 7.60 N/A
MJAKG121 X 6.14 / 8.38 N/A
MJAKG122 X 6.50 / 8.87 N/A
MJAKG123 X 7.17 / 9.77 N/A
RS340, RS380 096642 4.11 70745 16.5” gearing; 5/8” bolt holes
096643 4.33 70745 16.5” gearing; 5/8” bolt holes
096644 4.56 70745 16.5” gearing; 5/8” bolt holes
RT340, RT380 098117 4.56 / 6.21 87955 16.5” gearing; 5/8” bolt holes
S230, S260 300KG100 X 3.07 300KY100 X
300KG107 X 3.54 300KY100 X
300KG103 X 3.73 300KY100 X
Axle Model
Ring & Pinion
Kit Part #
Ratio Ring Gear Bolt Kits Notes
