Spicer Ford Applications 1999-2011 Light Axle Parts - Manual (Page 84)

Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
X510-2
84
Kits & Parts - Use With All Applications
606227 606228 606263 606310 606321
1 Inner Pinion Bearing Kit 3 707447X 707447X 707447X 707447X 707065X
2 Seal - Pinion 8 46411 46411 46411 46411 46411
3 End Yoke or Comp.Flange (inc 10) 9 3-­4-­11081-­1X 3-­4-­11281-­1X 3-­4-­11081-­1X 3-­4-­11081-­1X 76809X
4 Slinger 10 231872 231872 231872 231872 42432
5 KIT - Carrier Cover - 707479X 707478X 707479X 707479X 707231X
6 Cover - Carrier 13 47717-1 47843 47717-1 47717-1 42434
7 Bolt -­ Carrier Cover(qty 10) 15 34822 47508-­3 34822 34822 34822
8 Gear -­ Differential (std) 26 42411 43652 42411 42411 42411
9 Seal -­ Oil (Inner Wheel) 30 47507 47860 47507 47507 47507
10 Bearing Cone - Inner Wheel 31 565906 566071 565906 565906 565906
11 Bearing Cone - Outer Wheel 33 565911 550348 565911 565911 565911
12 Retainer -­ Wheel Bearing (RH) 34 43075 47858 43075 43075 43075
13 Retainer -­ Wheel Bearing (LH) -­ 43075 47858 43075 43075 43075
14 Gasket 35 - - - - 39697
15 Screw & Lockwasher Assy 37 45816 45816 45816 45816 45720
16 Retainer Ring / O-­Ring 48 47893 47857 47893 47893 -­
606609 606610 606611 606612 606613
1 Inner Pinion Bearing Kit 3 707447X 707447X 707447X 707447X 707447X
2 Seal - Pinion 8 51690 51690 51690 51690 51690
3 End Yoke or Comp.Flange (inc 10) 9 3-­4-­9931-­1 84829 3-­4-­9931-­1 3-­4-­9931-­1 84829
4 Slinger 10 84406 84406 84406 84406 84406
5 KIT - Carrier Cover - 707479X 2015251 707479X 707479X 2015251
6 Cover - Carrier 13 47717-1 2013064 47717-1 47717-1 2013064
7 Bolt -­ Carrier Cover(qty 10) 15 34822 47508-­3 34822 34822 47508-­3
8 Gear -­ Differential (std) 26 42411 43652 42411 -­ 43652
9 Seal -­ Oil (Inner Wheel) 30 47507 47860 47507 47507 47860
10 Bearing Cone - Inner Wheel 31 565906 566071 565906 565906 566071
11 Bearing Cone - Outer Wheel 33 565911 550348 565911 565911 550348
12 Retainer -­ Wheel Bearing (RH) 34 43075 47858 43075 43075 47858
13 Retainer -­ Wheel Bearing (LH) -­ 43075 47858 43075 43075 47858
14 Gasket 35 - - - - -
15 Screw & Lockwasher Assy 37 45816 45816 45816 45816 45816
16 Retainer Ring / O-­Ring 48 47893 47857 47893 47893 47857
606614 606726 606727 606728 606773
1 Inner Pinion Bearing Kit 3 707447X 707447X 707447X 707447X 707447X
2 Seal - Pinion 8 51690 51690 51690 51690 51690
3 End Yoke or Comp.Flange (inc 10) 9 3-­4-­9931-­1 84794 84794 84794 84794
4 Slinger 10 84406 84406 84406 84406 84406
5 KIT - Carrier Cover - 707479X 707479X 707479X 707479X 707479X
6 Cover - Carrier 13 47717-1 47717-1 47717-1 47717-1 47717-1
7 Bolt -­ Carrier Cover(qty 10) 15 34822 47508-­1 47508-­1 47508-­1 34822
8 Gear -­ Differential (std) 26 42411 42411 -­ 42411 42411
9 Seal -­ Oil (Inner Wheel) 30 47507 47507 47507 47507 47507
10 Bearing Cone - Inner Wheel 31 565906 565906 565906 565906 565906
11 Bearing Cone - Outer Wheel 33 565911 565911 565911 565911 565911
12 Retainer -­ Wheel Bearing (RH) 34 43075 43075 43075 43075 43075
13 Retainer -­ Wheel Bearing (LH) -­ 43075 43075 43075 43075 43075
14 Gasket 35 - - - - -
15 Screw & Lockwasher Assy 37 45816 45816 45816 45816 45816
16 Retainer Ring / O-­Ring 48 47893 47893 47893 47893 47893
Ford 80 /286 Rear
