Parts Listing
23
X510-2
ITEM PART DESCRIPTION
NO. NUMBER
ITEM PART DESCRIPTION
NO. NUMBER
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(5) See Camber/Casting Bushing Table in the back of this catalog
Ford 60 /248 Front
1 -­(3) Housing -­ Axle Service
2 -­(1) Drive Pinion & Gear Kit
3 701161X Shim - Inner Pinion Adj Package
47890 Slinger (used on Dead Front only)
4 706046X Inner Pinion Bearing
5 30982 Baffle -­ Pinion Bearing
6 45658 Collapsible Spacer
7 706045X KIT - Outer Pinion Bearing
8 42737 Thrustwasher - Bearing
-­(2) PKG -­ Seal (inc 9 & 10)
9 -­(2) Seal -­ Pinion
10 47886 Seal -­ End Yoke
11 -­(2) End Yoke
12 30275 Washer - Pinion Nut
13 -­(2) Nut -­ Pinion
14 47707-1 Cover - Carrier
15 -­(2) Plug -­ Carrier Cover
16 47508-­2 Bolt -­ Carrier Cover (qty 10)
17 34687 Gasket - Carrier Cover
18 -­(3) Cap -­ Differential Bearing
19 48632-1 Bolt - Differential Bearing Cap
20 706047X KIT - Differential Bearing
21 708012 KIT -­ Diff Brg Adj Shim (inc 17)
22 -­(1) Case -­ Differential
23 40638 Bolt -­ Drive Gear (qty 12)
24 -­(2) Pinion -­ Differential
25 -­(2) Thrustwasher -­ Diff Pinion
26 -­(2) Gear -­ Differential (std)
27 34729 Thrustwasher - Diff Gear
28 44810 Lock - Differential Shaft
29 30263 Shaft - Differential
30 52148 Seal - Guide Tube
31 -­(2) Guide Tube
700238-2X KIT - Socket Assembly
(inc 32,33,35,36,37 & 38)
32 44101 Nut - Hex Slotted
33 500024-8 Pin - Cotter
34 -­(2) Bushing
-­(5) (Alternate Bushing Selection)
35 2001257 Socket - Upper
36 44133 Nut -­ Hex Jam
37 2001258 Socket - Lower
38 620343 Snap Ring
39 -­(2) Nut -­ Knuckle
40 47816(3) Stud
41 -­(3) Knuckle -­ Right
42 -­(3) Knuckle -­ Left
43 50381 Seal - Oil
44 -­(1) Shaft & Joint Assembly
45 -­(2) Seal -­ Oil
46 47766 Thrustwasher
47 -­(2) Dust Shield
48 41784-2 O-Ring
49 -­(3) Hub Assembly
701166X PKG -­ Thrustwasher (inc 50 & 51)
50 47760(4) Thrustwasher
51 47759(4) Thrustwasher
52 620142 Snap Ring
