Spicer Ford Applications 1999-2011 Light Axle Parts - Manual (Page 83)

Variable Parts Listing
X510-2
83
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section) 2012030 2012199 2013831 2013832 2013833
1 Inner Pinion Bearing Kit 3 707447X 707447X 707447X 707447X 707447X
2 Seal - Pinion 8 51690 51690 51690 51690 51690
3 End Yoke or Comp.Flange (inc 10) 9 84794 84794 84794 84794 84794
4 Slinger 10 84406 84406 84406 84406 84406
5 KIT - Carrier Cover - 2003447 2003447 2013834 2013834 2013834
6 Cover - Carrier 13 2002316 2002316 2012630 2012630 2012630
7 Bolt -­ Carrier Cover(qty 10) 15 47508-­3 47508-­3 47508-­3 47508-­3 47508-­3
8 Gear -­ Differential (std) 26 42411 -­ 42411 42411 -­
9 Seal -­ Oil (Inner Wheel) 30 47507 47507 47507 47507 47507
10 Bearing Cone - Inner Wheel 31 565906 565906 565906 565906 565906
11 Bearing Cone - Outer Wheel 33 565911 565911 565911 565911 565911
12 Retainer -­ Wheel Bearing (RH) 34 43075 43075 43075 43075 43075
13 Retainer -­ Wheel Bearing (LH) -­ 43075 43075 43075 43075 43075
14 Gasket 35 - - - - -
15 Screw & Lockwasher Assy 37 45816 45816 45816 45816 45816
16 Retainer Ring / O-­Ring 48 47893 47893 47893 47893 47893
605924 605925 605926 605942 605944
1 Inner Pinion Bearing Kit 3 707447X 707447X 707447X 707447X 707447X
2 Seal - Pinion 8 46411 46411 46411 46411 46411
3 End Yoke or Comp.Flange (inc 10) 9 3-­4-­11081-­1X 3-­4-­11281-­1X 3-­4-­11081-­1X 3-­4-­11081-­1X 3-­4-­11281-­1X
4 Slinger 10 231872 231872 231872 231872 231872
5 KIT - Carrier Cover - 707479X 707478X 707479X 707479X 707478X
6 Cover - Carrier 13 47717-1 47843 47717-1 47717-1 47843
7 Bolt -­ Carrier Cover(qty 10) 15 34822 47508-­3 34822 34822 47508-­3
8 Gear -­ Differential (std) 26 42411 43652 42411 -­ 43652
9 Seal -­ Oil (Inner Wheel) 30 47507 47860 47507 47507 47860
10 Bearing Cone - Inner Wheel 31 565906 566071 565906 565906 566071
11 Bearing Cone - Outer Wheel 33 565911 550348 565911 565911 550348
12 Retainer -­ Wheel Bearing (RH) 34 43075 47858 43075 43075 47858
13 Retainer -­ Wheel Bearing (LH) -­ 43075 47858 43075 43075 47858
14 Gasket 35 - - - - -
15 Screw & Lockwasher Assy 37 45816 45816 45816 45816 45816
16 Retainer Ring / O-­Ring 48 47893 47857 47893 47893 47857
606144 606217 606224 606225 606226
1 Inner Pinion Bearing Kit 3 707065X 707065X 707447X 707447X 707447X
2 Seal - Pinion 8 46411 46411 46411 46411 46411
3 End Yoke or Comp.Flange (inc 10) 9 76809X 76809X 3-­4-­11081-­1X 3-­4-­11281-­1X 3-­4-­11081-­1X
4 Slinger 10 42432 42432 231872 231872 231872
5 KIT - Carrier Cover - 707231X 707231X 707479X 707478X 707479X
6 Cover - Carrier 13 42434 42434 47717-1 47843 47717-1
7 Bolt -­ Carrier Cover(qty 10) 15 34822 34822 34822 47508-­3 34822
8 Gear -­ Differential (std) 26 42411 42411 42411 43652 42411
9 Seal -­ Oil (Inner Wheel) 30 47507 47507 47507 47860 47507
10 Bearing Cone - Inner Wheel 31 565906 565906 565906 566071 565906
11 Bearing Cone - Outer Wheel 33 565911 565911 565911 550348 565911
12 Retainer -­ Wheel Bearing (RH) 34 43075 43075 43075 47858 43075
13 Retainer -­ Wheel Bearing (LH) -­ 43075 43075 43075 47858 43075
14 Gasket 35 39697 39697 - - -
15 Screw & Lockwasher Assy 37 45720 45720 45816 45816 45816
16 Retainer Ring / O-­Ring 48 -­ -­ 47893 47857 47893
Ford 80 /286 Rear
