Variable parts listing – Spicer FRONT & REAR AXLE KIT MISCELLANEOUS MODELS 1979-1984 User Manual
Page 6

5
X510-7
ITEM
PART
DESCRIPTION
NO.
NUMBER
ITEM
PART
DESCRIPTION
NO.
NUMBER
Parts Listing
Model 44 /216 Rear Axles - Avanti
1
—
(3)
Carrier
2
—
(1)
Drive Pinion & Gear Assembly
3
—
(2)
KIT – Inner Pinion Bearing
—
(2)
PKG – Pinion Shim
(inc. items 4, 5, 6, 8)
—
(2)
PKG – Differential & Pinion Shim
(inc. items 4, 5, 6, 8, 21)
4
—
Shim – Drive Pinion Adjusting
5
—
Shim – Pinion Bearing Adjusting
6
—
KIT – Outer Pinion Bearing
7
—
(2)
8
—
Slinger – Outer Pinion Bearing
9
—
Seal – Pinion Oil
10
—
(2) (5)
End Yoke Assembly
11
—
Washer – Pinion Nut
12
—
Pinion Nut
13
—
(5)
Companion Flange Assembly
—
(2)
KIT – Carrier Cover
14
—
Carrier Cover
15
—
Gasket – Carrier Cover
16
—
Plug – Carrier Cover
17
—
Bolt – Carrier Cover (qty 10)
18
—
(3)
Cap – Differential Bearing
19
—
(3)
Bolt – Differential Bearing Cap
20
—
(2)
KIT – Differential Bearing
21
—
(2)
PKG – Differential Bearing Shim
22
—
(1)
Case – Differential
23
—
Bolt – Drive Gear (qty 10)
24
—
Pinion – Differential
25
—
Gear – Differential
26
—
Thrustwasher – Differential Pinion
27
—
Thrustwasher – Differential Gear
28
—
Shaft – Differential Pinion
29
—
Lock – Differential Shaft
30
—
Bolt – Brake Mounting
31
—
Nut – Brake Mounting
—
(2)
KIT – Rear Axle Shaft
(inc. items 32, 33, 34, 35, 36, 37)
—
(2)
KIT – Unit Bearing & Seal
(inc. items 32, 33, 34, 35, 36)
32
—
Seal – Inboard Shaft
33
—
Retainer Ring – Wheel Bearing
34
—
Wheel Bearing Assembly
35
—
(3)
Seal – Outboard Shaft
36
—
Retainer – Oil Seal
37
—
Shaft – Axle Flanged Drive
38
—
(1)
Case – Differential
39
—
Gear – Differential
40
—
Shaft – Differential
41
—
Snap Ring
42
—
Spacer– Differential Gear (dished)
43
—
Plate– Differential
44
—
Disc – Differential
45
—
Plate– Diff. (selective thickness)
46
—
Clip – Differential Clutch Retainer
(1) See "Bill of Material Table"
(2) See "Variable Parts Table"
(3) Contact Vehicle Manufacturer.
(4) Not Sold Separately.
(5) See Spicer U-Joint Catalog J300P-10 for part number and additional parts.
603894
605113
605220
1
KIT – Inner Pinion Bearing
3
706031X
706031X
706123X
2
PKG – Pinion Shim
-
706358X
706358X
—
3
PKG – Differential & Pinion Shim
-
706376X
706376X
—
4
KIT – Outer Pinion Bearing
7
706030X
706030X
706996X
5
End Yoke Assembly
10
2-4-2281X
2-4-2281-1X
2-4-3801-1X
6
KIT – Differential Bearing
20
706032X
706032X
706988X
7
PKG – Differential Bearing Shim
21
706086X
706086X
701005X
8
KIT – Carrier Cover
-
706694X
706694X
—
9
KIT – Rear Axle Shaft
-
706550X
706550X
707018X
10
KIT – Unit Bearing & Seal
-
706012
706012X
—
Kits & Parts - Use With All Applications
Description & Item Number
Bills of Material
(Refer to "Exploded View")
Variable Parts Listing
