Spicer FRONT & REAR AXLE KIT MISCELLANEOUS MODELS 1979-1984 User Manual
Page 18

17
X510-7
ITEM
PART
DESCRIPTION
NO.
NUMBER
ITEM
PART
DESCRIPTION
NO.
NUMBER
Parts Listing
Model 44 /216 Front Axles - Converters
1
—
(3)
Housing – Axle Service
2
—
(1)
Drive Pinion & Gear Assembly
3
Slinger – Inner Pinion Bearing
4
706031X
KIT – Inner Pinion Bearing
706358X
PKG – Pinion Shim
(inc. items 3, 5, 6, 7, 9)
706376X
PKG – Differential & Pinion Shim
(inc. items 3, 5, 6, 7, 9, 21, 22)
5
—
Shim – Drive Pinion Adjusting
6
—
Baffle – Pinion Bearing
7
—
Shim – Pinion Bearing Adjusting
8
706030X
KIT – Outer Pinion Bearing
9
—
Slinger – Outer Pinion Bearing
10
—
Seal – Pinion Oil
11
2-4-2281X
(5)
End Yoke Assembly
12
—
Washer – Pinion Nut
13
—
Pinion Nut
14
—
(5)
Companion Flange Assembly
706112X
KIT – Carrier Cover (inc. 15,16,17,18)
15
—
Carrier Cover
16
—
Gasket – Carrier Cover
17
—
Plug – Carrier Cover
18
—
Bolt – Carrier Cover (qty 10)
19
—
(3)
Cap – Differential Bearing
20
—
(3)
Bolt – Differential Bearing Cap
21
706032X
KIT – Differential Bearing
22
706086X
PKG – Differential Bearing Shim
23
—
(1)
Case – Differential
24
—
Bolt – Drive Gear (qty 10)
25
—
Pinion – Differential
26
—
Gear – Differential
27
—
Thrustwasher – Differential Pinion
28
—
Thrustwasher – Differential Gear
29
—
Shaft – Differential Pinion
30
—
Lock – Differential Shaft
31
—
Seal & Guide Tube
—
(3)
KIT – Right Hand Knuckle
(32,33,34,35,36,37,38,39,40,41,42)
—
(3)
KIT – Left Hand Knuckle
(32,33,34,35,36,37,38,39,40,41,42)
706116X
KIT – Socket
(inc. 32, 33, 34, 35, 36, 37, 38)
32
—
Nut – Hex Slotted
33
—
Cotter Pin
34
—
Adjusting Split Ring
35
—
Socket Assembly – Upper
36
—
Nut – Hex Jam
37
—
Socket Assembly – Lower
38
—
Snap Ring
39
—
Stop Screw
40
—
Jam Nut
41
—
Knuckle Assembly
42
—
Nut - Hex Slotted
43
—
Cotter Pin
44
—
Tie Rod Assembly
45
—
Shaft & Joint Assembly
5-297X
U-Joint Kit
—
(2)
KIT – Spindle Seal & Bearing
(inc. items 47, 48, 49, 50, 51)
—
(2)
KIT – Spindle
(inc. items 47, 48, 49, 50, 51, 52)
46
—
Slinger – Spindle Yoke
(pressed on if used)
47
—
Oil Seal
48
—
Spacer – Wheel Bearing Spindle
49
—
Oil Seal – Block Vee
50
—
Needle Bearing Assembly
51
—
Wheel Bearing Spindle
52
—
Nut – Brake Mounting
53
—
Oil Seal
54
—
(2)
KIT – Inner Wheel Bearing
55
—
Wheel Hub
56
—
(2)
KIT – Outer Wheel Bearing
57
—
Lockwasher – Wheel Bearing
58
—
Nut – Wheel Bearing
59
—
Lockwasher – Wheel Bearing Nut
60
—
Gasket – Drive Flange
61
—
Flange – Axle Drive
62
—
Snap RIng
63
—
Hub Cap
64
—
Nut
65
—
Lockwasher
66
—
Stud
67
—
Wheel Bearing Spindle
68
—
Oil Seal
69
—
KIT – Inner Wheel Bearing
70
—
Wheel Hub
71
—
KIT – Outer Wheel Bearing
72
—
Nut & Pin Assembly
73
—
Lock – Retaining Nut
74
—
Nut – Wheel Bearing Adjusting
75
—
Plate – Spring Retaining
76
—
Spring – Pressure
77
—
Gear – Axle Drive
78
—
Hub Cap
—
(2)
Wheel End Kits
(1) See "Bill of Material Table"
(2) See "Variable Parts Table"
(3) Contact Vehicle Manufacturer.
(4) Not Sold Separately.
(5) See Spicer U-Joint Catalog J300P-10 for part number and additional parts.
