Page 10

9
X510-7
ITEM
PART
DESCRIPTION
NO.
NUMBER
ITEM
PART
DESCRIPTION
NO.
NUMBER
Parts Listing
Model 44 /216 Rear Axles - Checker Cab
1
—
(3)
Housing – Axle Service
2
—
(1)
Drive Pinion & Gear Assembly
3
706031X
KIT – Inner Pinion Bearing
706358X
PKG – Pinion Shim
(inc. items 4, 5, 6, 8)
706376X
PKG – Differential & Pinion Shim
(inc. items 4, 5, 6, 8, 21)
4
—
Shim – Drive Pinion Adjusting
5
—
Baffle – Pinion Bearing
6
—
Shim – Pinion Bearing Adjusting
7
706030X
KIT – Outer Pinion Bearing
8
—
Slinger – Outer Pinion Bearing
9
—
Seal – Pinion Oil
10
2-4-2281X
(5)
End Yoke Assembly
11
—
Washer – Pinion Nut
12
—
Pinion Nut
13
—
(5)
Companion Flange Assembly
706694X
KIT – Carrier Cover (inc. 14,15,16,17)
14
—
Carrier Cover
15
—
Gasket – Carrier Cover
16
—
Plug – Carrier Cover
17
—
Bolt – Carrier Cover (qty 10)
18
—
(3)
Cap – Differential Bearing
19
—
(3)
Bolt – Differential Bearing Cap
20
706032X
KIT – Differential Bearing
21
706086X
PKG – Differential Bearing Shim
22
—
(1)
Case – Differential
23
—
Bolt – Drive Gear (qty 10)
24
—
Pinion – Differential
25
—
Gear – Differential
26
—
Thrustwasher – Differential Pinion
27
—
Thrustwasher – Differential Gear
28
—
Shaft – Differential Pinion
29
—
Lock – Differential Shaft
30
—
Bolt – Brake Mounting
31
—
Nut – Brake Mounting
706328X
KIT – Rear Axle Shaft
(inc. items 32, 33, 34, 35, 36, 37)
706517X
KIT – Unit Bearing & Seal
(inc. items 32, 33, 34, 35, 36)
32
—
Seal – Inboard Shaft
33
—
Retainer Ring – Wheel Bearing
34
—
Wheel Bearing Assembly
35
—
(3)
Seal – Outboard Shaft
36
—
Retainer – Oil Seal
37
—
Shaft – Axle Flanged Drive
38
—
(1)
Case – Differential
39
—
Gear – Differential
40
—
Shaft – Differential
41
—
Snap Ring
42
—
Spacer– Differential Gear (dished)
43
—
Plate– Differential
44
—
Disc – Differential
45
—
Plate– Diff. (selective thickness)
46
—
Clip – Differential Clutch Retainer
(1) See "Bill of Material Table"
(2) See "Variable Parts Table"
(3) Contact Vehicle Manufacturer.
(4) Not Sold Separately.
(5) See Spicer U-Joint Catalog J300P-10 for part number and additional parts.
1979-83 Checker Cab
603835-1
Standard
3.07
706017-1X
706020X
706024X
706027X
27360X
27360X
603835-2
Trac Lok
3.07
706017-1X
706018X
706022X
706027X
27360X
27360X
603835-3
Standard
2.72
706017-19X
706020X
706024X
706027X
27360X
27360X
603835-4
Trac Lok
2.72
706017-19X
706018X
706022X
706026X
27360X
27360X
603835-5
Trac Lok
3.54
706017-3X
706018X
706022X
706026X
27360X
27360X
(6)
See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(7)
See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
Axle
Axle Kits
Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit
(6)
Case Assy.
Kit
(7)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
Bill of Material Listing
