14
Qty
Item Description Per D590 Notes
Axle D590D
40 INTER-AXLE DIFFERENTIAL 1 139965
41 Helical Side Gear & Bushing Assy. 1.39:1 1 131346 Gear stamp id# 131341, includes item 42
42 Bushing - Helical Gear 2 131344
43 Thrust Washer 1 132440*
44 Sliding Clutch 1 131332
45 V-ring 1 131333*
KIT - SHIFT FORK & SPRING 1 514142 Includes items 46-47
46 Compression Spring 1 129859
47 Shift Fork Assembly - NSS 1 131330-NSS Must order kit above
KIT - INPUT SHAFT - PUMP MDL 1 513840 Includes items 48, 60 & 65
48 Input Shaft - NSS - PUMP 1 131349-NSS
49 Bearing Cone - Input Shaft 1 139973*
KIT - AIR LOCKOUT REPAIR 1 512892 Includes items 50-53
50 Piston 1 131232
51 O-Ring - Piston 1 210180
52 O-Ring Cover 1 131665 Production#131665, alternate service# is 220HH102
53 Piston Cover 1 131096
KIT - INPUT COVER 1 504066 Includes items 49, 54-58A
54 Input Cover - 131328-NSS 1 131687 Order 504066 kit
55 Capscrew - Input Cover 12 131374
56 Nut - Adjuster Stud 1 131693 M12 thread
57 Stud - Adjuster 1 131692 M12 thread
58 Input Adjuster & Cup Assy. 1 134354
58A Brg Cup - Input Adjuster 1 139974* Part of item# 58
KIT - INPUT SEAL & LOCKNUT 1 131008K Includes items 59-60 & 65
59 Input Seal 1 134323* Sold in 131008K kit also
KIT - PINION NUT 1 131095K Includes item 60 & 65
60 Locknut - Input Shaft 1 131095 Socket size 69mm
61 Cover - Diff Lock Shift 1 131096 For Non-diff lock mdls. For diff lock models see Pg 34
62 Plug - Diff Lock Shift 1 127195 For Non-diff lock mdls. For diff lock models see Pg 34
63 O-Ring - Diff Lock Cover 1 131665 For Non-diff lock mdls. For diff lock models see Pg 34
64 Plug & O-Ring - Diff Lock Cylinder 1 131487 For Non-diff lock mdls. For diff lock models see Pg 34
65 Loctite Adhesive .5ml tube 1 129293 Not illustrated
66 RTV Sealant - 3oz 1 107276S* Not illustrated
Service Diff Carrier Sub-Assembly
Item Model Part No. Notes
1 D590, D590D 132485 Includes items 1-4
Carrier Sub-Assembly Identification Information:
Part No. Casting # Notes
132485 131322 Built w/Pilot Web (D590, D590D)
D590 / D590D Axle Parts List
