Spicer TIMS (Tire Inflation Monitor System) - Manual (Page 11)

Index
9
Index
Page Description Part No. Page Description Part No.
512411
System Control Kit - 1.8m (6 ft) 8
512412 System Control Kit - 7.6m (25ft) 8
512413 Axle Kit - D22 1.75” 8
512414 Axle Kit - P22 2.50” 8
512415 Axle Kit - P22 2.75” 8
513504 Wheel End Kit - D22 1.75” 8
513505 Wheel End Kit - P22 2.50” 8
513506 Wheel End Kit - P22 2.75” 8
513974 Tire Hose Kit - Dual 22.5” 8
513975 Tire Hose Kit - Dual 19.5” 8
513976 Tire Hose Kit - Wide Base Single 8
673500 Spacer, 5.50 B.C., .5” thick 6
676347 Mounting Cylinder, P (2.50) 5
676349 Label, Check Tire 4
676364 Mounting Cylinder, J (1.75) 5
676374 O-ring, Rotary Joint 7
676378 Jam nut, 5/8” - 18 6
676384 Clamp, Stepless Ear (Oetiker) 5
676385 Plug Assy, P22 Axle (2.50) 5
676669 Tire Hose - Dual, 180 end 6 o
676648 Tire Hose - Dual, Straight end 6
676671 Tee Fitting 6
676397 Plug Assy, D22 Axle (1.75) 5
676400 Hubcap, 5.5” B.C., grease - D22 6
676401 Hubcap, 5.5” B.C., oil - D22 6
676467 PCU 4
676411 Hubcap, 6.75” B.C., grease - P22 6
676412 Hubcap, 6.75” B.C., oil - P22 6
676644 Bracket 4
676652 Bolts, ECU 4
676667 Bolts, PCU 4
676447 Plug Assy, S.A.P. 225P Axle (2.75) 5
676448 Mounting Cylinder, S.A.P. P (2.75) 5
676450 Rotary Joint Assy 5
676452 Label, Information 4
676673 90 Fitting, Hubcap Super Single 6
676461 Tool, Plug Installation, 1.75” 7
676462 Tool, Plug Installation, 2.50” 7
676463 Tool, Plug Installation, 2.75” 7
676464 Filter, PCU - cone 7
676472 Seal, Tire hose 7
676473 Hose Assy, Axle Inlet - female 1/4” NPT 5
676649 Tire Hose - Straight 6
676670 Tire Hose - Dual, 180 end 6
o
676484 Label, System Maintenance 4
676495 Pressure Sensor 4
676608 Harness - 1.8m (6 ft) 5
676609 Harness - 7.6m (25 ft) 5
676631 ECU 4
676651 TIMS Controller Assy 4
676672 Wheel End Guard 6
676641 Tire Hose Assy with Check Valve 6
676642 Tire Hose Assy with Check Valve 6
676643 Tire Hose Assy with Check 6
969143 Gasket, 5.50” B.C. - D22 6
M10HG138 Gasket, 6.75” B.C. - P22 6
N/A Tool handle, Universal 7
N/A Oetiker Clamp Tool 7
o
676678 Filter, PCU - cylinder 7
676665 Cover, PCU 7
676666 Filter Cap, PCU 7
676645 Plug, Oil Hubcap 7
676653 TIMS Controller Assy, Bendix TABS6 7
