Introduction
Introduction
Dana Commercial Vehicle Division, presents this publication to aid in maintenance and overhaul of Spicer single drive axles.
Instructions contained cover the models listed. Their design is common, with differences in load capacity. Capacity variations
are achieved by combining basic differential carrier assemblies with different axle housings, axle shafts and wheel equipment.
Model Listing
Model Information
Rear Axle Load Capacity
S19-140 19,000
S17-140 17,000
S 19 - 1 4 0 L
S - S i n g l e R e a r A x l e
O p t i o n s
L - L i m i t e d - S l i p
W - W i d e - t r a c k
F - R o l l e d O v e r
R - P a r k i n g B r a k e
G e a r Ty p e
1 - S t a n d a r d S i n g l e R e d u c t i o n
2 - D u a l R a n g e
3 - P l a n e t a r y D o u b l e R e d u c t i o n
4 - C o n t r o l l e d Tr a c t i o n D i f f e r e n t i a l
5 - H e l i c a l R e d u c t i o n
D e s i g n L e v e l
H e a d A s s e m b l y S e r i e s
G AW R a t i n g x 1 0 0 0 l b s .
