Page 13
10
Differential Carrier Assembly
Differential Carrier
Assembl
y
Remove Differential Carrier
Standard Differentials
1.
Block the vehicle.
2.
Drain axle lubricant. Remove bottom two (2) cap-
screws.
3.
Disconnect driveline.
4.
Remove axle shafts. (If used, remove lock washers
and taper dowels.)
Do not lie under carrier after fasteners are removed. Use
transmission jack to support differential carrier assembly
prior to loosening fasteners.
Do not strike the shaft head with a steel hammer. Do not
use chisels or wedges to loosen shaft or dowels.
5.
Remove carrier capscrews and washers.
6.
Remove differential carrier assembly.
WARNING
WARNING
CAUTION
CAUTION
