1350 tube type, Series 1350, Tube type assembly – Spicer 10 Series Driveshafts User Manual
Page 9
Tube Type Assembly
Standard Tube Size 3.0" x 0.083 (76.2mm x 2.11mm)
Tube Part Number 24-30-42
Series 1350
9
10 Series
© 2005 Dana Corporation
Minimum Length
Slip Joint End
Tight Joint End
Assembly
Collapsed
Part Number
FF-FF
CL-CL
Flange Yoke
U-Joint
Slip Yoke
Tube Shaft
Tube Yoke
U-Joint
Flange Yoke
Flange Face
Centerline
or S.S.
Kit
Assembly
Kit
or S.S.
to
to
(Shipping
(Includes
(Shipping
Flange Face
Centerline
Strap)
Dust Cap Kit)
Strap)
J = 1.500" - (38.1mm) - 16 Spline S = 2.000" - (50.8mm)
Tubing Formula: T =
CL-CL
(Collapsed) minus 8.750" - (222.2mm)
10.12"
S.S
5-178X
3-3-598KX
3-40-1471
3-28-47
5-178X
S.S.
910598 (1)
(257.0
mm
)
J = 1.500" - (38.1mm) - 16 Spline S = 3.624" - (92.0mm)
Tubing Formula: T =
CL-CL
(Collapsed) minus 13.590" - (345.1mm) Minimum T = 1.470" - (37.3mm)
15.12"
12.00"
3-2-119
5-480X
3-3-488KX
3-40-1611
3-28-57
5-480X
3-2-119
909048
(384.0
mm
)
(304.8
mm
)
(1) Non-Standard tube size 2.5" x 0.083" (63.5 mm x 2.11 mm) Part #20-30-22
