Spicer 10 Series Driveshafts - Manual (Page 13)

Coupling Shaft Assembly
Standard Parts
Standard Tube Size 3.5" x 0.083" (88.90mm x 2.11mm)
Tube Part # 28-30-62
Nut 16-74-101
Series 1410
13
10 Series
© 2005 Dana Corporation
Minimum Length Tight Joint End Center Bearing End Assembly
Collapsed Part Number
FF-FF CL-CL Flange Yoke U-Joint Tube Yoke Tubing Midship Center End Yoke
Flange Face Centerline or S.S. Kit Tube Shaft Bearing (Assy)/
to to (Shipping Companion
Centerline Centerline Strap) Flange
Tubing Formula: T = CL-CL (Collapsed) minus 7.810" - (198.3 mm)
9.19” S.S 5-462X 3-28-557 28-30-62 3-53-1791 210391-1X 3-4-6561 905771
(233.4 mm )
Tubing Formula: T = FF- CL (Collapsed) minus 8.500" - (215.9mm)
10.88” 9.19” 3-2-159 5-462X 3-28-557 28-30-62 3-53-1791 210873-1X 3-4-6561-1 911159
(276.3 mm ) (233.4 mm )
Tubing Formula: T = FF-FF (Collapsed) minus 8.660" - (219.9mm)
10.16” 8.47” 3-2-159 5-160X 3-28-97 24-30-42 3-53-1881 210391-1X 3-1-4621 917043 (1)
(258.0 mm ) (215.1 mm )
(1) Non-Standard tube size 3.0" x 0.083" (76.2 mm x 2.11 mm) Part #24-30-42
4.13”
(104.9mm)
4.13”
(104.9mm)
3.25”
(82.5mm)
R
Center Bearing to
End Yoke/Flange
Face
