1810 coupling shaft, Series 1810, Coupling shaft assembly – Spicer 10 Series Driveshafts User Manual
Page 53
Coupling Shaft Assembly
Standard Parts
Standard Tube Size 4.5" x 0.134" (114.3mm x 3.40mm)
Tube Part # 36-30-62
Washer 230123-6
Nut 20-74-91
Series 1810
53
10 Series
© 2005 Dana Corporation
Tubing Formula: T =
CL-CL
(Collapsed) minus 11.590” - (294.4mm)
14.20”
S.S.
5-676X
5.6-28-117
36-30-62
6.5-53-171
210661-1x
6.5-4-3591-1
804149
(360.7
mm
)
14.20”
S.S.
5-676X
5.6-28-127
36-30-22
6.5-53-181
210661-1x
6.5-4-3591-1
804248 (1)
(360.7
mm
)
Tubing Formula: T = FF-FF (Collapsed) minus 14.970” - (380.2mm)
17.60”
14.22”
6.5-2-329
5-281X
6.5-28-117
36-30-62
6.5-53-91
210875-1x
6.5-4-1891
911617
(447.0
mm
)
(361.2
mm
)
Minimum Length
Tight Joint End
Center Bearing End
Assembly
Collapsed
Part Number
FF-FF
CL-CL
Flange Yoke
U-Joint
Tube yoke
Tubing
Midship
Center
End Yoke
Flange Face
Centerline
or S.S.
Kit
Tube Shaft
Bearing
(Assy)
to
to
(Shipping
Flange Face
Centerline
Strap)
(1) Non-Standard tube size 4.50" x 0.259" (114.3 mm x 6.58 mm) Part #36-30-22
R
Center Bearing
to
End Yoke/Flange
Face
6.2”
(157.5mm)
6.2”
(157.5mm)
6.2”
(157.5mm)
