15
4.5 Main Display Setup
The main Display Setup controls how the software will display the results. To launch this interface,
go to Setup / Display setup.
4.5.1 Display Setup Tab
The display setup tab allows to edit the main interface appearance. The number of display areas
can be defined and their individual display setups can be defined in the Display Area Setup
interface by clicking on the gear icon of each display.
4.5.1.1 Display Area Setup Interface
The display area setup interface defines the display type and data type of a specific display area.
The available display types are:
• Time history graph,
• 1/3 octave spectrum graph
• FFT spectrum graph
• Numerical indicator
