9
4 Software Description
4.1 Main Interface
The main interface is used for both performing a measurement and post-processing.
Main Interface
4.1.1 Measure Controls
The measure controls are related to the acquisition behavior. The top indicator shows the elapsed
time when measuring.
The RUN/LOG/STOP button controls the measurement. Two modes are available:
• Log on start;
• View before log.
Measure
Controls
File Info
Audio
Controls
Main Time Axis
Display Area
Legend Display Settings
Rescale Axis
