Thanks for choosing a KC HiLiTES product. We take pride in building the
highest quality, best engineered systems possible. Your satisfaction with our
product is important, so if you have any questions, please call our customer
service line at 800-528-0950.
Installing the Bar
Attaching a Hi-Lift Jack
Adding KC Lights
1. Remove the six bolts securing the
hood to the hinges .
2. Place the KC bar on top of the
hinges and align the bolt holes on
the hood, hinge and bar .
3. Using the bolts and washers
supplied, start threading the bolts
in each of the six holes.
4. Ensure all parts are aligned
properly, then tighten all six bolts.
1. Find the two collared bolts included and insert them
head first into the end of each of the slots on top of the
bar. Position them so they will fit through any of the
holes in the Hi-Lift jack.
2. Attach the wing nuts to hold the jack in place.
We suggest one of the KC SportLite series lights, as these will fit easily hanging
from any of the three light tabs on the bar. Call KC HiLiTES at the number below
for a current catalog and suggested options.
You’re DONE! - - - - - - - Enjoy your new KC products.
Installation Instructions for KC 7404
97 - 05 Jeep
Hood Mount Utility Bar
For
Wrangler
KC HiLiTES, Inc. 2843 West Avenida de Luces, Williams, Arizona 86046-0155 * 800-528-0950 * www.kchilites.com
KC3263F - rev 050105
