KC HiLiTES KC #42302 2007-2013 JEEP WRANGLER (JK) H4 “DOT” HEADLIGHT CONVERSION KIT Instructions - Manual

KC HiLiTES, Inc. Post Office Box 155, Williams, Arizona 86046-0155 * 800-528-0950 * www.kchilites.com
See details on our website at
www.kchilites.com
23 Year Warranty
2 - #4230 H4 HEADLIGHTS
2 - H4 PHILIPS 55/60W BULBS
1 - #6307 H13-H4 CONVERSION HARNESS KIT
• 10mm Socket/Wrench
• T15 Torx Driver
• Flathead Screwdriver
• Philips Screwdriver**
**Note: For earlier JK Models with Screw-type Retainer
Tabs, it requires a Philips Screwdriver.
Pop open your Hood. Using a 10mm wrench,
the (-) NegaƟve Terminal from the baƩery.
the Turn Signal Wire Harness behind the grill
through the wheel well and the connector by
pulling out the red locking tab.
the connector by pressing and holding the
release tab down while you pull it out.
Using the Flathead Screwdriver, the (6) PlasƟc
Retainer Tabs located along the top of the grill shroud by
liŌing the plasƟc pins and gently prying the tabs out. (For
older model JKs, it will require using a Philips Screwdriver
to unscrew the plasƟc liŌ pins.)
#42302 HEADLIGHT CONVERSION KIT INCLUDES:
TOOLS REQ’D FOR INSTALLATION:
INSTALLATION:
1.
2.
3.
4.
the Jeep Wrangler Grille by firmly pulling on
the lower part of the grille unƟl the retainer clips break
free of the chassis.
Using the T15 Torx Driver: the (4) retaining ring
screws holding the headlight assembly in place.
headlight assembly out to expose the wire harness
with connector. the headlight by unlocking the
connector by sliding out the red locking tab, press and
hold the release tab and disconnect the connector.
the Retainer Ring from the OEM Headlight and
discard the OEM Headlight.
Take the H13-H4 Harnesses Adapter (#6307) and
the Male H13 plug to the OEM Connector.
Take the KC H4 Headlight and it to the H4
connector from the Harness Adapter (#6307).
The KC H4 Headlight is indexed to align with the Jeep
Wrangler Headlight Housing. Make sure the indexed tabs
are properly aligned before screwing the retainer ring
back into place using the original T15 Retainer Ring
Screws.
the Jeep Wrangler Grille by following Steps
(1-7) in reverse order.
Enjoy your New H4 Headlights!
5.
Tip: There are (6) Press-In Retainer Clips holding the Jeep Grille
in place: (1) Located Above each turn signal (Le & Right) and
(5) located along the bo om of the lower radiator support.
6.
7.
8.
9.
10.
11.
12.
#42302
2007-2013 JEEP WRANGLER (JK)
H4 “DOT” HEADLIGHT CONVERSION KIT
