High Lifter Lift Kit for Kawasaki Mule 4010 - Manual (Page 3)

6. Once the bottom of the strut has been loosened, then unbolt the top of the strut. The nuts securing the
top strut can be located in the dash of the Mule on the left and right sides. In most cases these nuts are
easily accessible, but you may have to remove the glove box or heater coils, depending on the model and
options purchased with the Mule.
7. Remove the nuts that secure the strut and then pull strut from the strut mount. If strut is hard to remove,
you may have to open the mount up.
Large Screwdriver
8. Remove the retaining nut and washer from the top of the strut. Next remove the factory rubber
mount/bushing, coil retaining cup and boot.
3
