Front lift installation – High Lifter Lift Kit for Kawasaki Mule 4010 User Manual
Page 2
Front Lift Installation
1. Ensuring that the parking brake is set, place jack under center of the Mule front end and lift until front
wheels clear the ground. Be careful to support Mule properly so that it is secure, but so that the A-arms
and struts can droop to full extension.
2. Remove front wheels.
3. If applicable, remove the heater to allow access to the strut mount behind the heater coil.
Heater
4. Starting with the left side (driver side), remove the cotter pin and castle nut that secures the strut to the
strut mount.
Castle Nut & Pen
5. Push bolt through the bolthole, taking care not to damage the brake line that is attached to the bolt. If
you are having difficulty removing the bolt, you may have to remove the brake lines that are attached to
the front brakes. In this case refer to owners manual for removing brake lines.
Screwdriver
NOTE: Keep in mind that if you remove the brake lines you must bleed your brakes according to operator’s
manual.
2
