High Lifter Max Clearance Front Forward Upper & Lower Control Arms for Polaris RZR 800 "S_"4"" - Manual (Page 6)

6
11. When reconnecting the lower arm to the knuckle assemble, install the bolt in the
opposite direction from stock. Using the 10mm x 60mm bolt and 10mm lock nut
provided, insert it from rear to front. VERY IMPORTANT TO DO THIS OR
IT WILL HIT THE ARM!
12. Once you have installed the new forward arms, reconnect the tie rod end to the
knuckle assembly using the factory hardware.
NOTE: See notes on aligning the front wheels at the end of instructions!
13. Make sure to insert factory approved grease into the new fittings and use zip ties
to secure the brake line to the arm.
14. Place wheels back on UTV torque lugs to factory specifications.
