High Lifter Tie Rod_Rack End Upgrade Kit for Polaris Ranger 500_700_800_900 Pro Series User Manual
Page 4
10. If you have not done so already install the jam nut back onto the rod end. Then, place the hex
bar onto the rod.
11. Locate the new heim joint and place the jam nut onto it. Make sure you run the jam nut all the
way down to the bottom of the threads.
12. Install the heim joint into the hex bar.
13. Using a ½” drill bit or equivalent, open the hole of the knuckle assemble to ½”.
