9
strato
A* = observe overlay !
X Y
420 – 500 mm
500 – 550 mm
550 – 650 mm
255 mm
342 – 420 mm 186 mm
293.5 mm
313.5 mm
*
A
2
3
2
3
2
3
2
3
2
3
2
3
8
Y Y
X
Ø3.2 (M4)
Drilling diagram for
reverse side of flap
Design for 20 mm aluminum frame profile.
Cabinet height 420-650 mm
*
A
Drill holes for flap in according to the
drilling diagram. Lift-up fitting – strato
7
