342 1,5 – 4,0 4,0 – 7,2 6,5 – 11,5
—
342 – 420 03.3685.011.001 03.3685.011.002 03.3685.011.003
420 2,0 – 3,5 3,5 – 7,0 6,5 – 11,0 8,0 – 16,0
420 – 500 03.3685.012.001 03.3685.012.002 03.3685.012.003 03.3685.012.004
500
— —
3,8 – 10,0 6,0 – 15,0
500 – 550 03.3685.013.003 03.3685.013.004
600
— —
3,5 – 10,0 6,0 – 14,5
550 – 650 03.3685.014.003 03.3685.014.004
1
strato
The correct model results from the height and weight of the flap, see chart. Choose the transversal
stabilization bar according to the width of your cabinet.
LIft-up fitting strato (without transversal stabilization bar)
Cabinet height
[ mm ]
Flap weight / Part-No.
[ kg ]
23 Choosing the correct lift-up fitting strato model.
