Hafele EN 372.67 Series User Manual
Page 5
5
strato
verso
40
72
168
V
32
2
3
6
9
A
W
Schrankhöhe
Cabinet height
Hauteur de meuble
Altezza armadio
Altura del mueble
[ mm ]
V
W
min.
420 - 800
37 mm
138 mm
50 mm
151 mm
37 mm
138 mm
342 - 420
420 - 650
huwilift-
verso
huwilift-
strato
Drilled holes
A= Ø 5 mm x min. X deep
5
Ш
16
12
5
Ш
19
15
Design for all cabinet heights
View of right inner side. (left side symmetrical)
Drilling depth
3
Drill holes for fitting in accordance with
the drilling diagram. Lift-up fitting verso/strato
