Inclination of the flap in closed position
The flap inclination is adjusted at the excenter 7 of the receptive base plate for the traction lever.
+
-
-
+
Ø4 / SW 4
SW 19
7
17
Fine-adjust according to flap inclination.
Lift-up verso/strato
View of right side. (left side symmetrical)
