IPDirector Version 5.6– User Manual – Part 4: Ingest
EVS Broadcast Equipment – May 2009
Issue 5.6.D
15
2.4 RECORDER CHANNELS STATUS AREA
2.4.1 C
HANNEL
N
AME
The ingest channels are displayed following the Channel Display order configured
in the user settings.
The recorders and streams are grouped by logical entity, which is herafter referred
to as a track: the channels recording the same video content are grouped
together. For each channel, an expanded view displays the items chosen in the
Display Options menu, in the following order:
In hi-res/lo-res mode
•
hi-res XT recorder
• hi-res stream
• lo-res XT recorder
• lo-res stream.
In hi-res only mode
•
hi-res XT recorder
• hi-res stream
Some warning information may be displayed through red border or red stream
name. Refer to section 2.6.5 ‘Warning Messages’ on page 25.
