Xedio Suite Version 4.2 – User Manual - Xedio Cutter
EVS Broadcast Equipment – June 2012
Issue 4.2.B
3
Area Description
show black bars as these mattes are part of the video
signal
When the Preview button is clicked, the Player window is
replaced by the Storyboard Preview window.
2. Media Manager This is used to select the media to view in the Player
window. It has the same powerful filtering and search
attributes as other parts of the Xedio Suite of
applications: this makes finding the required material an
easy process.
3. Storyboard When clips are ready to export, they are added to the
Storyboard area using the drag-and-drop technique. The
order in which the clips appear in the list will be the order
they are placed when exported.
1.3 PROCESS OVERVIEW
The use of Xedio Cutter can be summarized as follows:
Step See …
1. Select a media from the Media Manager Section 2 on page 4
2. Load it on the Player Pane Section 3.5 on page 25
3. Make a new clip Section 3.6 on page 26
4. Send the clip to the Storyboard Section 4.2.1 on page 27
5. Preview the Storyboard in the Player Pane Section 4.3 on page 29
6. Export the Storyboard Section 4.4 on page 30
