Issue 4.2.B Xedio Suite Version 4.2 – User Manual - Xedio Cutter
EVS Broadcast Equipment – June 2012
2
1.2.2 O
VERVIEW OF THE
X
EDIO
C
UTTER
W
INDOW
The Xedio Cutter graphical interface consists of three main areas, besides the
Menu bar. They are highlighted on the following screenshot and shortly described
in the table below.
Note
The color of some user interface elements may vary with the Xedio skin
installed.
Area Description
1. Player Pane This is used to load and play media, to make clips and
create the elements to place into the storyboard area. All
types of media and clips can be played back but clips can
only be made from video assets.
Everything that is outside the video content has the skin
color. Video such as letterboxed or pillarboxed video will
