• to Target
This allows you to export a storyboard according to a predefined Export Target profile
(RTProf) or to a predefined XSquare target.
4.4.2. Exporting the Storyboard to Edit
How to Export the List to CleanEdit
To export the storyboard to CleanEdit for use on the timeline, proceed as follows:
1. Select the To Edit tab.
2. Select a user from the User field.
3. (optional) Select a class from the Class field.
4. Enter a project name in the Project field. This could be an existing known project from
the selected user or a new project name.
5. Enter a new edit name in the Edit field to place the clips in the timeline in the same
order as they appear in the storyboard.
6. A text note can be added and linked to the edit. Click the Story Text button on the
panel and enter the desired text.
7. Click the Send button.
A confirmation message will be displayed in case of successful edit creation in the
database. Click OK.
Audio Management for the Exported Edit
Clips copied to the storyboard do not have necessarily the same audio tracks. The
number of audio channels in the exported edit cannot exceed 16. So, in certain
circumstances, some audio channels will be discarded.
The rules applied for the selection of audio channels are the following:
1. Audio channels are taken in the order clips are listed in the storyboard.
2. The largest tracks are taken into account first: 5.1 tracks, then stereo tracks, then
mono tracks.
3. When the maximum number or audio channels (16) is reached, the other ones are
discarded from the exported edit.
