EVS Broadcast Equipment S.A.

Issue 2.6.A October 2013

6

OpenCube MXFTk® Front-End in Practice

XDCam HD: this will create an Op1a file following the exact properties of a SONY
XDCam Optical HD file. You will need to provide one MPEG2 HD following Sony’s
requirements and 4 or 8 audio channels depending on the profile.

P2: this will create a set of 3 or 5 OpAtom1b files following the exact properties of
Panasonic P2 files. You will need to provide 1 DVCPro (25, 50 or 100 Mb/s) file or 1
AVC-Intra (50 or 100Mbps) file and two or four 1-channel AES audio file or two or four
1-channel WAV files.

Panasonic AVC-LongG: this will create an Op1b file following the exact properties of
Panasonic AVC-LongG file. You will need to provide 1 AVC/H.264 file, an optional
ancillary file and a number of 1-channel AES/WAV audio files.

XDCam IMX SxS: this will create an Op1a file following the exact properties of a
SONY XDCam SxS IMX file. You will need to provide one IMX sequence (50 Mb/s)
and one 8-channel AES audio file.

XDCam DV SxS: this will create an Op1a file following the exact properties of a
SONY XDCam SxS DV file. You will need to provide one DV IEC sequence and four
1-channel AES file or four 1-channel WAV files.

XDCam HD SxS: this will create an Op1a file following the exact properties of a
SONY XDCam SxS HD file. You will need to provide one MPEG2 HD following
Sony’s requirements and 4 or 8 audio channels depending on the profile.

Avid OpAtom: This will create OpAtom files. These MXF can be natively edited by
an Avid editing system.

Avid OpAtom AMT: Same as Avid OpAtom but uses Avid Media Toolkit (AMT)
provided by Avid instead of OpenCube implementation.

AS-02: this will create an AS-02 MXF file. AS-02 is an Application Specification
defined by the American Media Workflow Association (AMWA) aiming at creating a
factory format.

AS-03: this will create an AS-03 MXF file. AS-03 is an Application Specification
defined by the American Media Workflow Association (AMWA). It defines a vendor-
neutral subset of the MXF Op1a file format.

AS-11: This will create an AS-11 MXF file. AS-11 is an Application Specification
defined by the American Media Workflow Association (AMWA). It defines a vendor-
neutral subset of the MXF Op1a file format. You will need to provide one IMX or AVC-
Intra sequence and audio files.

AS-11 (UK DPP): This will create an AS-11 MXF file compliant with the UK DPP
Shim.

IMF Essence Component: This will create an IMF MXF file compliant with the
SMPTE ST2067-2 Core Constraints.

After choosing the operational pattern you can adjust the number of parallel packages
(the number of source packages that will be played simultaneously) with the control box
(2) and the number of play-list packages (the number of source packages that will be
played sequentially) with the control box (8). The view (9) is a summary of the material
package of the MXF file. It represents the output timeline of your MXF file.

In the drop-down box (4) you can select one of the source packages and edit its content.
In the list box (6) you will find a summary of the media files embedded in the current
package. You can remove some of them by selecting them and clicking on Remove (12).
In order to add a media file to that package, click on Add (13). This will open a new dialog
where you will be able to select a single file sequence (dv, dif, mpg, imx, etc.) or a multi-
file sequence (j2k, bmp, etc.).
