List of Video Inputs

The list of video inputs displays the following information:

Field

Description

Input

Video input name.

Recorder

Recorder assigned to the input.

InputType

Type of the input. The user must tell the application
which video input is the director's cut, and which are
camera inputs.

Capacity

The capacity left on the recorder (for example, two
hours).

Audio

Checkbox allowing to add in the list of audio inputs
below as many audio lines as audio channels available
for the recorder assigned to the current video input.

Managing the Audio Inputs

Possible Actions

In order to ...

Proceed as follows:

Add audio inputs

In the list of video inputs, tick the audio checkbox of the
associated recorder. Audio inputs (4, 8, 16) are added in
the list.

Remove audio inputs

In the list of video inputs, untick the audio checkbox of
the associated recorder. Audio inputs are removed from
the list.

List of Audio Inputs

There can be at most 24 audio inputs in the list, regardless of the number of video inputs
they are associated to.

The list of audio inputs displays the following information:

Field

Description

Input

Name of the associated video input.

Channel N°

Audio channel number.

Name

Name of the audio input. If needed, edit the field and set
a name to the audio input, for example "FrontL",
"BackR", etc.

8

2. Configuring the Production

EVS Broadcast Equipment S.A. - November 2012

Issue 6.00.B
