Selecting a Switcher Gateway
Select the EVS switcher gateway from the Switcher Gateway dropdown list.
When the system tries to establish the connection to the switcher gateway, a status
message is displayed above the field: “Connecting ...”. If the connection has failed, the
message becomes “Connection error ...”. When the connection is successfully
established, the message becomes "Connected", and the recorders video inputs are
automatically added in the Video Input Assignment list.
Note
When working without an EVS switcher gateway, the operator must manually
add the recorders video inputs. In this case, the director's cut points will not be
written in the metadata EDL.
Managing the Video Inputs
Possible Actions
Note
Managing video inputs manually is possible only if no switcher gateway is
selected.
In order to ... Proceed as follows:
Add a video input Click the button. An item is appended to
the list of video inputs.
Remove a video input Select an item from the list of video inputs, and click the
button. The selected item disappears.
Warning
There is no confirmation asked when removing
an item. This action is not reversible.
Actualize the list Click the button.
IPDirector - Version 6.00 - User Manual - Director's Cut
2. Configuring the Production 7
