INITIAL SETTING
LPCM setup
This option sets the audio output format sent using the
unit's coaxial digital audio output.
In the Linear PCM setting, “48K” means
“the digital audio output maximum sampling rate is
48KHz”; therefore, when the title's encoding sampling
rate* is 96KHz, the output will be forced converted to
48KHz.
If “96K” is selected, then the maximum
output-sampling rate is 96KHz and no conversion will
take place.
Sampling rate:
When a sound wave is converted to a digital signal, the sound is sampled and converted to data at
a specific frequency rate. For example, a signal with a 96 kHz sampling rate indicates that in one
second, the analog signal was sampled 96000 times to produce the digital signal.
In LPCM set-up menu, there will be a case that even when “LPCM 96K” is selected, output signal
is converted to 48KHz if the disc has the copy guard management system in it.
Linear PCM OUT
LPCM 48K
LPCM 96K
-
-
Notes:
l
l
l
l
- - LPCM SETUP - -
LPCM OUT
MAIN PAGE
LPCM 48K
LPCM 96K
Disc
DVD
Audio encoding format
Dolby Digital
®
Linear PCM
(48/96kHz, 24bits)
Digital output format
Dolby Digital Bit stream
(1~5.1 ch) or 48kHz/16bits
2ch Linear PCM
Linear PCM
(48KHz/16 bits)
Disc coding and output format
Video CD
Audio CD
MPEG 1
Linear PCM
Linear PCM
(44.1KHz sampling)
Linear PCM
(44.1kHz/16bit)
