Quick Setup Guide
Doc. No. ASE/MXO/PLM/ 0141/ EN Rev.C Date: 01.12.2011 8/34
3.2 Configuration
In this configuration example, we used the following information:
Direct SIP connection using TCP as transport
MX-ONE Telephony System
• IP address: 192.168.222.56
• FQDN:sn3112.roadrunner.as.zr.zeruela.lab.se
• Numbering Plan: 5 digits
• IP extensions numbers for Voice Mail and Auto Attendant: 55555 and 55559.
• Route access code: 055
• Users IP extensions: 21167, 21168 and 21169
Exchange UM
• IPv4: 192.168.222.97
• FQDN: stoexc2.as.zr.zeruela.lab.se
• Voice Mail Pilot identifier, Hunt Group: 55555
• Auto Attendant: 55559
3.2.1 MX-ONE configuration:
3.2.1.1 Creating SIP trunk
The following commands shall be executed in MX-ONE to configure a SIP Trunk.
ROCAI:ROU=55,SEL=7110000000000010,SIG=0111110000A0,TRAF=03151515,TRM=4,SERV
=3100000001,BCAP=000100;
#varc d5=1 (forced gateway)
#varo d6=9 (9s timeout for 100 Trying)
RODAI:ROU=55,TYPE=TL66,VARI=00000011,VARC=00001000,VARO=00000900;
#Node 1 (as in node x, as in TRU=x-1) for MX-ONE SIP access, in this case the IP address
192.168.222.56 is configured in the Telephony Server 1.
ROEQI:ROU=55,TRU=1-1;
Outbound Setting:
sip_route -set -route 55 -uristring sip:[email protected] –remoteport 5065 -fromuri0
sip:[email protected] -protocol tcp -codecs PCMA
Inbound Setting:
